Long Flanged Caps for Straight Threads

FCSL


Polyethylene Plastic Long Flanged Caps for Standard Threads
Long Flanged Caps for Straight Threads

FCSL–Product Media

Long Flanged Caps for Straight Threads Large Protection Caps Standard Straight Threads - Plastic Long Flanged Caps Long Flanged Plastic Caps for Standard Straight Threads Long Flanged Caps for Straight Threads Polyethylene Plastic Long Flanged Caps for Standard Threads Plastic Long Flanged Caps for Standard Threads Standard Straight Threads - Plastic Long Flanged Caps Long Flanged Plastic Caps for Standard Straight Threads Long Flanged Caps for Straight Threads
  • Material: LDPE (Low Density Polyethylene) (Red)
  • Flanged for Easy Removal
  • Use as Thread Protector or End Cap

Available in the following varieties:

FCS - Flanged Caps for Straight Threads Flanged Plastic Caps for Standard Straight Threads
FCSL - Long Flanged Caps for Straight Threads Long Flanged Caps for Straight Threads
FCM - Flanged Caps for Metric Threads Flanged Plastic Caps for Metric Threads
FCBN - Flanged Caps for BSP and NPT Threads Flanged Plastic Caps for BSP and NPT Threads

Size Chart Standard Straight Threads - Plastic Long Flanged Caps

FCSL Size Chart

Table View
List View
Part # Description To Fit STD Thread Inside Diameter
mm
in
 Flange OD
mm
in
 Inside Length
mm
in
 Box/Mini/Micro
QTY		 See Prices / Buy Online
FCSL.313 Long Flanged Caps for Straight Threads - FLANGE CAP FOR 5/16" STR THRDS 1.240" LONG LDPE 5/16
7.8
0.308
11.7
0.460
31.5
1.240
 5000 1000 100
FCSL.375 Long Flanged Plastic Caps for Standard Straight Threads - FLANGE CAP FOR 3/8" STR THRDS 1.240" LONG LDPE 3/8
9.4
0.370
13.2
0.520
31.5
1.240
 5000 1000 100
FCSL.437 Standard Straight Threads - Plastic Long Flanged Caps - FLANGE CAP FOR 7/16" STR THRDS 1.330" LONG LDPE 7/16
10.9
0.429
14.7
0.580
33.8
1.330
 5000 1000 100
FCSL.500 Plastic Long Flanged Caps for Standard Threads - FLANGE CAP FOR 1/2" STR THRDS 1.330" LONG LDPE 1/2
12.4
0.490
16.3
0.640
33.8
1.330
 5000 1000 100
FCSL.563 Polyethylene Plastic Long Flanged Caps for Standard Threads - FLANGE CAP FOR 9/16" STR THRDS 1.410" LONG LDPE 9/16
14.0
0.552
17.8
0.700
35.8
1.410
 5000 1000 100
FCSL.750 Long Flanged Caps for Straight Threads - FLANGE CAP FOR 3/4" STR THRDS 1.560" LONG LDPE 3/4
18.8
0.739
22.4
0.880
39.6
1.560
 2500 500 50
FCSL.750L Long Flanged Plastic Caps for Standard Straight Threads - FLANGE CAP FOR 3/4" STR THRDS 2.660" LONG LDPE 3/4
18.8
0.739
22.4
0.880
67.6
2.660
 2000 400 40
FCSL.875 Standard Straight Threads - Plastic Long Flanged Caps - FLANGE CAP FOR 7/8" STR THRDS 1.700" LONG LDPE 7/8
21.9
0.861
25.7
1.010
43.2
1.700
 2500 500 50
FCSL.875L Large Protection Caps - FLANGE CAP FOR 7/8" STR THRDS 2.660" LONG LDPE 7/8
21.9
0.861
25.7
1.010
67.6
2.660
 1500 300 30
FCSL1.000 Long Flanged Caps for Straight Threads - FLANGE CAP FOR 1" STR THRDS 1.800" LONG LDPE 1
25.1
0.988
29.2
1.150
45.7
1.800
 1500 300 30
FCSL1.062 Long Flanged Plastic Caps for Standard Straight Threads - FLANGE CAP FOR 1-1/16" STR THRDS 1.890" LONG LDPE 1-1/16
26.6
1.049
30.2
1.190
48.0
1.890
 1000 200 20
FCSL1.062L Standard Straight Threads - Plastic Long Flanged Caps - FLANGE CAP FOR 1-1/16" STR THRDS 3.000" LONG LDPE 1-1/16
26.6
1.049
30.2
1.190
76.2
3.000
 900 180 18
FCSL1.125 Plastic Long Flanged Caps for Standard Threads - FLANGE CAP FOR 1-1/8" STR THRDS 2.120" LONG LDPE 1-1/8
28.3
1.113
31.8
1.250
53.8
2.120
 1500 300 30
FCSL1.125L Polyethylene Plastic Long Flanged Caps for Standard Threads - FLANGE CAP FOR 1-1/8" STR THRDS 3.100" LONG LDPE 1-1/8
28.3
1.113
31.8
1.250
78.7
3.100
 900 180 18
FCSL1.313 Long Flanged Caps for Straight Threads - FLANGE CAP FOR 1-5/16" STR THRDS 1.890" LONG LDPE 1-5/16
33.0
1.299
36.6
1.440
48.0
1.890
 1000 200 20
FCSL1.625 Long Flanged Plastic Caps for Standard Straight Threads - FLANGE CAP FOR 1-5/8" STR THRDS 1.920" LONG LDPE 1-5/8
40.9
1.611
44.7
1.760
48.8
1.920
 500 100 10
FCSL1.875 Standard Straight Threads - Plastic Long Flanged Caps - FLANGE CAP FOR 1-7/8" STR THRDS 1.940" LONG LDPE 1-7/8
47.3
1.861
51.1
2.010
49.3
1.940
 300 60 6
Part # Description To Fit STD Thread Inside Diameter
mm
in
 Flange OD
mm
in
 Inside Length
mm
in
 Box/Mini/Micro
QTY		 See Prices / Buy Online
Legend:
- Add to Basket - View Price

Micropacks are only available for purchase through our online store.



Not sure what part you need? Would you like to consider another type or part, or a different material?
Consult MOCAP's Application Advisor for assistance.



Long Flanged Caps for Straight Threads - Information

MOCAP Long Flange Caps are designed to protect standard straight threads. The natural colour of the plastic flange caps allow for visual verification of the threads or o-ring. Flange caps for standard straight threads are easy to assemble or remove by hand or automated equipment.
These Flanged Caps feature a longer length than our standard FCS Series flanged caps, adding extra protection for parts with increased thread length. Protects components or fittings from moisture, dust and damage during production, shipping and storage, and can also be used as low-temp masking during painting and plating. Our FCSL Series Caps are moulded in Natural polyethylene plastic and sized to cap Straight threads from 5/16" thru 1-7/8".

Many Sizes of Our Long Flanged Caps for Straight Threads are Stocked for Immediate Shipment.


Most stock sizes are available in Mini-Packs when Smaller Quantities are Needed. To place an order for this product, call 0800 046 7436 or use our Contact Request Form to receive information by e-mail.







RoHS


Diagram
