Pull Tab Vinyl Plastic Caps
D
Round Grab Tab Caps
View Larger Image
D–Product Media
- Material: Vinyl
- Flexible Yet Durable - Won't Split, Tear or Shred
- Flat / Ergonomic Tab for Easy Removal
- Stretches for a Snug Fit but Won't Split, Tear or Shred
Size Chart PVC Pull Tab Caps
D Size Chart
| Part # | Description | Inside Diameter mm in |
Min Inside Length mm in |
Max Inside Length mm in |
Wall Thickness mm in |
Tab Height mm in |
Stocked Length mm |
Box/Mini/Micro QTY |
See Prices / Buy Online |
|---|---|---|---|---|---|---|---|---|---|
| D4.8FPTS | UK Pull Tab Vinyl Plastic Caps 4.8MM X ?MM | 4.8 0.189 |
6.4 0.250 |
25.4 1.000 |
1.0 0.039 |
12.7 0.500 |
12.7 | 5320 1064 106 | |
| D5.5FPTS | UK Pull Tag Caps 5.5MM X ?MM | 5.5 0.215 |
6.4 0.250 |
25.4 1.000 |
1.0 0.039 |
12.7 0.500 |
12.7 | 4900 980 98 | |
| D6.0FPTS | UK Plastic Pull Tag Caps 6.0MM X ?MM | 6.0 0.236 |
6.4 0.250 |
25.4 1.000 |
1.0 0.039 |
12.7 0.500 |
12.7 | 4998 999 99 | |
| D6.4FPTS | UK Plastic Pullable Caps 6.4MM X ?MM | 6.4 0.250 |
6.4 0.250 |
25.4 1.000 |
1.0 0.039 |
12.7 0.500 |
12.7 | 4845 969 96 | |
| D8.0FPTS | UK Round Grab Tab Caps 8.0MM X ?MM | 8.0 0.313 |
6.4 0.250 |
38.1 1.500 |
1.0 0.039 |
16.6 0.655 |
25.4 | 2484 496 49 | |
| D8.7FPTS | UK Rubber Caps with Grabbable Tab 8.7MM X ?MM | 8.7 0.343 |
6.4 0.250 |
38.1 1.500 |
1.0 0.039 |
17.7 0.695 |
25.4 | 2520 504 50 | |
| D9.5FPTS | UK Caps with Plastic Grab Tag 9.5MM X ?MM | 9.5 0.375 |
6.4 0.250 |
38.1 1.500 |
1.0 0.039 |
17.7 0.695 |
25.4 | 2310 462 46 | |
| D10.3FPTS | UK PVC Pull Tab Caps 10.3MM X ?MM | 10.3 0.406 |
6.4 0.250 |
38.1 1.500 |
1.4 0.055 |
18.0 0.709 |
25.4 | 2310 462 46 | |
| D11.1FPTS | UK Pull Tab Vinyl Caps 11.1MM X ?MM | 11.1 0.437 |
6.4 0.250 |
38.1 1.500 |
1.4 0.055 |
18.4 0.725 |
25.4 | 2376 475 47 | |
| D11.7FPTS | UK Pull Tab Vinyl Plastic Caps 11.7MM X ?MM | 11.7 0.460 |
6.4 0.250 |
38.1 1.500 |
1.4 0.055 |
19.1 0.750 |
25.4 | 2079 415 41 | |
| D12.7FPTS | UK Pull Tag Caps 12.7MM X ?MM | 12.7 0.500 |
6.4 0.250 |
38.1 1.500 |
1.5 0.060 |
19.1 0.752 |
25.4 | 2079 415 41 | |
| D13.5FPTS | UK Plastic Pull Tag Caps 13.5MM X ?MM | 13.5 0.531 |
6.4 0.250 |
38.1 1.500 |
1.5 0.060 |
19.4 0.764 |
38.1 | 1026 205 20 | |
| D14.3FPTS | UK Plastic Pullable Caps 14.3MM X ?MM | 14.3 0.562 |
6.4 0.250 |
38.1 1.500 |
1.5 0.060 |
15.6 0.613 |
38.1 | 1026 205 20 | |
| D15.9FPTS | UK Round Grab Tab Caps 15.9MM X ?MM | 15.9 0.625 |
6.4 0.250 |
38.1 1.500 |
1.5 0.060 |
18.0 0.709 |
38.1 | 972 194 19 | |
| D16.6FPTS | UK Rubber Caps with Grabbable Tab 16.6MM X ?MM | 16.6 0.655 |
6.4 0.250 |
38.1 1.500 |
1.5 0.060 |
20.6 0.812 |
38.1 | 918 183 18 | |
| D17.5FPTS | UK Caps with Plastic Grab Tag 17.4MM X ?MM | 17.5 0.687 |
6.4 0.250 |
38.1 1.500 |
1.5 0.060 |
20.6 0.812 |
38.1 | 918 183 18 | |
| D19.0FPTS | UK PVC Pull Tab Caps 19.0MM X ?MM | 19.0 0.748 |
6.4 0.250 |
38.1 1.500 |
1.5 0.060 |
21.0 0.826 |
38.1 | 750 150 15 | |
| D20.6FPTS | UK Pull Tab Vinyl Caps 20.6MM X ?MM | 20.6 0.812 |
6.4 0.250 |
50.8 2.000 |
1.5 0.060 |
21.3 0.837 |
38.1 | 675 135 13 | |
| D21.4FPTS | UK Pull Tab Vinyl Plastic Caps 21.4MM X ?MM | 21.4 0.843 |
6.4 0.250 |
38.1 1.500 |
1.5 0.060 |
21.5 0.846 |
38.1 | 630 126 12 | |
| D22.2FPTS | UK Pull Tag Caps 22.2MM X ?MM | 22.2 0.875 |
6.4 0.250 |
38.1 1.500 |
1.5 0.060 |
21.5 0.846 |
38.1 | 560 112 11 | |
| D23.8FPTS | UK Plastic Pull Tag Caps 23.8MM X ?MM | 23.8 0.937 |
6.4 0.250 |
38.1 1.500 |
1.5 0.060 |
21.7 0.853 |
38.1 | 455 91 9 | |
| D25.4FPTS | UK Plastic Pullable Caps 25.4MM X ?MM | 25.4 1.000 |
6.4 0.250 |
38.1 1.500 |
1.5 0.060 |
21.8 0.858 |
38.1 | 432 86 8 | |
| D27.0FPTS | UK Round Grab Tab Caps 27.0MM X ?MM | 27.0 1.062 |
6.4 0.250 |
38.1 1.500 |
1.5 0.060 |
21.8 0.858 |
38.1 | 308 61 6 | |
| D28.6FPTS | UK Rubber Caps with Grabbable Tab 28.6MM X ?MM | 28.6 1.125 |
6.4 0.250 |
50.8 2.000 |
1.5 0.060 |
21.8 0.858 |
- | -- -- -- | |
| D31.8FPTS | UK Caps with Plastic Grab Tag 31.8MM X ?MM | 31.8 1.250 |
6.4 0.250 |
50.8 2.000 |
1.5 0.060 |
21.8 0.858 |
38.1 | 560 112 11 | |
| Part # | Description | Inside Diameter mm in |
Min Inside Length mm in |
Max Inside Length mm in |
Wall Thickness mm in |
Tab Height mm in |
Stocked Length mm |
Box/Mini/Micro QTY |
See Prices / Buy Online |
Legend:
- Add to Basket
- View Price
'D' dimension varies by size. Contact MOCAP Sales for details.
Wall thickness is measured approx. 6.35mm (.25 inch) from open end. Wall thickness increases slightly towards the closed end of the part
Micropacks are only available for purchase through our online store.
Not sure what part you need? Would you like to consider another type or part, or a different material?
Consult MOCAP's Application Advisor for assistance.
Pull Tab Vinyl Plastic Caps - Information
MOCAP Pull Tab Vinyl Plastic Caps have an ergonomic design which allows for easy removal from your part. Pull tab plastic caps offer excellent protection from moisture and contaminates. These plastic caps stretch just enough to form for a secure fit and will not fall off during shipment.
Our round vinyl plastic pull tab caps can be produced in various colours, wall thicknesses, hardness durometers and lengths to 38.1mm (1-1/2"). The advantages of the vinyl dip moulding process allows MOCAP to offer any of these options with no additional tooling charges.MOCAP vinyl caps are often referred to as a rubber cap because of their pliable feel and flexibility. Use vinyl plastic caps as end caps, pipe caps, tube caps or for appearance finishing on your product. Pull tab plastic caps also provide inexpensive but tough protection to your valuable product line.
MOCAP can manufacture vinyl plastic pull tab caps made-to-order with the fastest lead-times in the industry.
- Flexible Vinyl Plastic for Snug Fit
- Ergonomic Tab for Easy Removal
- Sizes to Fit 4.8mm (3/16") to 31.8mm (1-1/2") Diameters
Product Protection
Use our pull tab vinyl plastic caps as durable and inexpensive caps to protect your product threads or surfaces during assembly or shipping.
Masking Applications
MOCAP vinyl plastic pull tab caps are often used as inexpensive and disposable single use masking caps for painting and coating processes under 212°F(100°C). The pull tab end makes removal easy. For higher temperatures, consider High Temperature Vinyl good to 446°F(230°C), EPDM Masking Products good to 300°F(149°C), or Silicone Masking Products good up to 600°F(316°C).
Most stock sizes are available in Mini-Packs when Smaller Quantities are Needed. To place an order for this product, call 0800 046 7436 or use our Contact Request Form to receive information by e-mail.
