Threaded Plastic Plugs for Straight Thread O-Ring Ports

OPP


Plugs for SAE O-Ring Ports and MIL-MS-33649 Bosses
Threaded Plastic Plugs for Straight Thread O-Ring Ports

OPP–Product Media

Threaded Plastic Plugs for Straight Thread O-Ring Ports Straight Thread O-Ring Port Plastic Plug Caps (MS33649) Plastic Bolt for Straight Thread O-Ring Ports Threaded Plugs for Straight Thread O-Ring Ports Threaded Plastic Plugs for Straight Thread O-Ring Ports Plugs for SAE O-Ring Ports and MIL-MS-33649 Bosses Straight Thread O-Ring Port Plastic Plug Caps (MS33649) Plastic Bolt for Straight Thread O-Ring Ports Threaded Plugs for Straight Thread O-Ring Ports
  • Material: PP (Polypropylene)
  • Stocked Material: PP (Red)
  • Designed to Provide a Positive Seal on SAE Straight-Thread O-Ring Type Ports and Mil-MS-33649 Bosses
  • Features Molded-In O-Ring Style Bead on the Outside of Head to Seal the Port Face from Oil Leakage

Size Chart Plastic Bolt for Straight Thread O-Ring Ports

OPP Size Chart

Table View
List View
Part # Description To Fit STD Thread Length
mm
in
Flange OD
mm
in
Flange Thickness
mm
in
Box/Mini/Micro
QTY
See Prices / Buy Online
OPP0438 Threaded Plastic Plugs for Straight Thread O-Ring Ports - PLUG FOR 7/16-20 STR THRD O-RING PORT 7/16 - 20
8.1
0.320
16.5
0.650
9.6
0.380
5000 1000 100
OPP0500 Threaded Plugs for Straight Thread O-Ring Ports - PLUG FOR 1/2-20 STR THRD O-RING PORT 1/2 - 20
8.1
0.320
18.3
0.720
9.6
0.380
5000 1000 100
OPP0562 Plastic Bolt for Straight Thread O-Ring Ports - PLUG FOR 9/16-18 STR THRD O-RING PORT 9/16 - 18
9.1
0.360
19.8
0.780
9.6
0.380
5000 1000 100
OPP0750 Straight Thread O-Ring Port Plastic Plug Caps (MS33649) - PLUG FOR 3/4-16 STR THRD O-RING PORT 3/4 - 16
10.2
0.400
24.9
0.980
9.6
0.380
5000 1000 100
OPP0875 Plugs for SAE O-Ring Ports and MIL-MS-33649 Bosses - PLUG FOR 7/8-14 STR THRD O-RING PORT 7/8 - 14
11.4
0.450
28.2
1.110
9.6
0.380
2500 500 50
OPP1062 Threaded Plastic Plugs for Straight Thread O-Ring Ports - PLUG FOR 1-1/16-12 STR THRD O-RING PORT 1-1/16 - 12
15.7
0.620
33.3
1.310
9.6
0.380
2500 500 50
OPP1312 Threaded Plugs for Straight Thread O-Ring Ports - PLUG FOR 1-5/16-12 STR THRD O-RING PORT 1-5/16 - 12
15.7
0.620
39.6
1.560
9.6
0.380
1000 200 20
OPP1625 Plastic Bolt for Straight Thread O-Ring Ports - PLUG FOR 1-5/8-12 STR THRD O-RING PORT 1-5/8 - 12
15.7
0.620
47.8
1.880
9.6
0.380
1000 200 20
Part # Description To Fit STD Thread Length
mm
in
Flange OD
mm
in
Flange Thickness
mm
in
Box/Mini/Micro
QTY
See Prices / Buy Online
Legend:
- Add to Basket - View Price

Micropacks are only available for purchase through our online store.



Not sure what part you need? Would you like to consider another type or part, or a different material?
Consult MOCAP's Application Advisor for assistance.



Threaded Plastic Plugs for Straight Thread O-Ring Ports - Information

MOCAP Threaded Plastic Plugs are designed for use on Straight Thread O-Ring Ports. These Threaded Plastic Plugs are ridged for easy use in manual assembly and removal.
They provide positive seal on SAE Straight Thread O-Ring type ports and MIL-MS-33649 bosses. Integrated O-ring type bead seats in the bevel of the port to prevent entrance of debris or contaminants and oil leakage. Seal at outside of ridge protects port face against paint and dirt.

Our OPP Series Threaded Plugs are moulded in Red polypropylene plastic and sized to fit Straight Thread O-Ring Ports from 7/16-20 thru 1-5/8-12.

Many Sizes of Our Threaded Plastic Plugs for Straight Thread O-Ring Ports are Stocked for Immediate Shipment.


Most stock sizes are available in Mini-Packs when Smaller Quantities are Needed. To place an order for this product, call 0800 046 7436 or use our Contact Request Form to receive information by e-mail.







RoHS


Diagram
