High Temperature Vinyl Pull Tab Caps

P


High Temp Vinyl Pull Tab Caps
High Temperature Vinyl Pull Tab Caps

P–Product Media

High Temp Vinyl Pull Tab Caps High-Temp Plastic Pull-Tab Caps High Temp Pull-Tab Caps High Temp Vinyl Pull Tab Caps High Temperature Vinyl Pull Tab Caps High Temp Vinyl Pull Tab Caps High-Temp Plastic Pull-Tab Caps High Temp Pull-Tab Caps
  • Material: High-Temp Vinyl (Black)
  • Flat / Ergonomic Tab for Easy Removal
  • Stretches for a Snug Fit but Won't Split, Tear or Shred

Size Chart High Temp Pull-Tab Caps

P Size Chart

Table View
List View
Part # Description Inside Diameter
mm
in
 Min Inside Length
mm
in
 Max Inside Length
mm
in
 Wall Thickness
mm
in
 Tab Height
mm
in
 Stocked Length
mm		 See Prices / Buy Online
D4.8FPTH UK High Temperature Vinyl Pull Tab Caps 4.8MM X ?MM
4.8
0.189
6.4
0.250
25.4
1.000
1.4
0.055
12.7
0.500
 -
D5.5FPTH UK High Temp Vinyl Pull Tab Caps 5.5MM X ?MM
5.5
0.215
6.4
0.250
25.4
1.000
1.4
0.055
12.7
0.500
 -
D6.0FPTH UK High Temp Pull-Tab Caps 6.0MM X ?MM
6.0
0.236
6.4
0.250
25.4
1.000
1.4
0.055
12.7
0.500
 -
D6.4FPTH UK High-Temp Plastic Pull-Tab Caps 6.4MM X ?MM
6.4
0.250
6.4
0.250
25.4
1.000
1.4
0.055
12.7
0.500
 -
D8.0FPTH UK High Temp Vinyl Pull Tab Caps 8.0MM X ?MM
8.0
0.313
6.4
0.250
38.1
1.500
1.4
0.055
16.6
0.655
 -
D8.7FPTH UK High Temperature Vinyl Pull Tab Caps 8.7MM X ?MM
8.7
0.343
6.4
0.250
38.1
1.500
1.4
0.055
17.7
0.695
 -
D9.5FPTH UK High Temp Vinyl Pull Tab Caps 9.5MM X ?MM
9.5
0.375
6.4
0.250
38.1
1.500
1.4
0.055
17.7
0.695
 -
D10.3FPTH UK High Temp Pull-Tab Caps 10.3MM X ?MM
10.3
0.406
6.4
0.250
38.1
1.500
1.4
0.055
18.0
0.709
 -
D11.1FPTH UK High-Temp Plastic Pull-Tab Caps 11.1MM X ?MM
11.1
0.437
6.4
0.250
38.1
1.500
1.4
0.055
18.4
0.725
 -
D11.7FPTH UK High Temperature Vinyl Pull Tab Caps 11.7MM X ?MM
11.7
0.460
6.4
0.250
38.1
1.500
1.4
0.055
19.1
0.750
 -
D12.7FPTH UK High Temp Vinyl Pull Tab Caps 12.7MM X ?MM
12.7
0.500
6.4
0.250
38.1
1.500
1.5
0.060
19.1
0.752
 -
D13.5FPTH UK High Temp Pull-Tab Caps 13.5MM X ?MM
13.5
0.531
6.4
0.250
38.1
1.500
1.5
0.060
19.4
0.764
 -
D14.3FPTH UK High-Temp Plastic Pull-Tab Caps 14.3MM X ?MM
14.3
0.562
6.4
0.250
38.1
1.500
1.5
0.060
15.6
0.613
 -
D15.9FPTH UK High Temp Vinyl Pull Tab Caps 15.9MM X ?MM
15.9
0.625
6.4
0.250
38.1
1.500
1.5
0.060
18.0
0.709
 -
D16.6FPTH UK High Temperature Vinyl Pull Tab Caps 16.6MM X ?MM
16.6
0.655
6.4
0.250
38.1
1.500
1.5
0.060
20.6
0.812
 -
D17.5FPTH UK High Temp Vinyl Pull Tab Caps 17.4MM X ?MM
17.5
0.687
6.4
0.250
38.1
1.500
1.5
0.060
20.6
0.812
 -
D19.0FPTH UK High Temp Pull-Tab Caps 19.0MM X ?MM
19.0
0.748
6.4
0.250
38.1
1.500
1.5
0.060
21.0
0.826
 -
D20.6FPTH UK High-Temp Plastic Pull-Tab Caps 20.6MM X ?MM
20.6
0.812
6.4
0.250
50.8
2.000
1.5
0.060
21.3
0.837
 -
D21.4FPTH UK High Temperature Vinyl Pull Tab Caps 21.4MM X ?MM
21.4
0.843
6.4
0.250
38.1
1.500
1.5
0.060
21.5
0.846
 -
D22.2FPTH UK High Temp Vinyl Pull Tab Caps 22.2MM X ?MM
22.2
0.875
6.4
0.250
38.1
1.500
1.5
0.060
21.5
0.846
 -
D23.8FPTH UK High Temp Pull-Tab Caps 23.8MM X ?MM
23.8
0.937
6.4
0.250
38.1
1.500
1.5
0.060
21.7
0.853
 -
D25.4FPTH UK High-Temp Plastic Pull-Tab Caps 25.4MM X ?MM
25.4
1.000
6.4
0.250
38.1
1.500
1.5
0.060
21.8
0.858
 -
D27.0FPTH UK High Temp Vinyl Pull Tab Caps 27.0MM X ?MM
27.0
1.062
6.4
0.250
38.1
1.500
1.5
0.060
21.8
0.858
 -
D28.6FPTH UK High Temperature Vinyl Pull Tab Caps 28.6MM X ?MM
28.6
1.125
6.4
0.250
50.8
2.000
1.5
0.060
21.8
0.858
 -
D31.8FPTH UK High Temp Vinyl Pull Tab Caps 31.8MM X ?MM
31.8
1.250
6.4
0.250
50.8
2.000
1.5
0.060
21.8
0.858
 -
Part # Description Inside Diameter
mm
in
 Min Inside Length
mm
in
 Max Inside Length
mm
in
 Wall Thickness
mm
in
 Tab Height
mm
in
 Stocked Length
mm		 See Prices / Buy Online
Legend:
- Add to Basket - View Price

'D' dimension varies by size. Contact MOCAP Sales for details.

Wall thickness is measured approx. 6.35mm (.25 inch) from open end. Wall thickness increases slightly towards the closed end of the part



Not sure what part you need? Would you like to consider another type or part, or a different material?
Consult MOCAP's Application Advisor for assistance.



High Temperature Vinyl Pull Tab Caps - Information

MOCAP High Temperature Vinyl Plastic Masking Caps are the low cost quality answer to your masking needs. Flexible material allows these plastic caps to seal round and odd shape items. Special high temperature resistant vinyl material withstands up to 446°F(230°C).
High temperature resistant pull tab caps are designed for easier application and removal.

High temp pull tab caps are available in sizes to fit 4.8mm (0.187") to 31.8mm (1.250") diameter applications.

High-temperature resistant round masking caps are also available in sizes to fit 1.6mm (0.062") to 214.0mm (8.425") diameter parts.

  • Special High Temperature Resistant Plastic Material
  • Sizes to Fit 4.8mm (0.187") to 31.8mm (1.250") Diameters
  • Pull Tab Design For Easy Removal









RoHS


Diagram
