Wide Flange Tapered Plastic Plug Caps

WF


Wide Flange Plastic Hole Stoppers
Wide Flange Tapered Plastic Plug Caps

WF–Product Media

Wide Flange Plug Caps Plastic Stoppers with Wide Flange Plastic End Caps with Wider Brim Wide Flange Plastic End Plugs Wide Flange Tapered Plastic Plug Caps Wide Flange Plastic Hole Stoppers Plastic Stoppers with Wide Flange Plastic End Caps with Wider Brim
  • Material: LDPE (Low Density Polyethylene) (Red)
  • Featuring a Wider Flange than the T Series for Added Protection of External Surfaces

Size Chart Plastic End Caps with Wider Brim

WF Size Chart

Table View
List View
Part # Description Small O.D.
mm
in
 Large O.D.
mm
in
 Small I.D.
mm
in
 Large I.D.
mm
in
 Length
mm
in
 Flange OD
mm
in
 Box/Mini/Micro
QTY		 See Prices / Buy Online
WF.173/.240 Wide Flange Tapered Plastic Plug Caps - WIDER FLANGE TAPERED PLUG CAP, LDPE
4.4
0.173
6.1
0.240
2.8
0.111
4.5
0.177
9.7
0.380
14.2
0.560
 5000 1000 100
WF.240/.315 Wide Flange Plastic End Plugs - WIDER FLANGE TAPERED PLUG CAP, LDPE
6.1
0.240
8.0
0.315
4.6
0.183
6.2
0.245
9.1
0.360
15.7
0.620
 5000 1000 100
WF.302/.375 Plastic End Caps with Wider Brim - WIDER FLANGE TAPERED PLUG CAP, LDPE
7.7
0.302
9.5
0.375
6.1
0.240
7.7
0.303
9.7
0.380
17.5
0.690
 5000 1000 100
WF.360/.425 Plastic Stoppers with Wide Flange - WIDER FLANGE TAPERED PLUG CAP, LDPE
9.1
0.360
10.8
0.425
7.6
0.298
9.2
0.363
9.7
0.380
19.1
0.750
 5000 1000 100
WF.425/.480 Wide Flange Plastic Hole Stoppers - WIDER FLANGE TAPERED PLUG CAP, LDPE
10.8
0.425
12.2
0.480
9.2
0.363
10.6
0.418
9.7
0.380
20.6
0.810
 5000 1000 100
WF.472/.540 Wide Flange Tapered Plastic Plug Caps - WIDER FLANGE TAPERED PLUG CAP, LDPE
12.0
0.472
13.7
0.540
10.4
0.410
12.1
0.478
11.2
0.440
22.4
0.880
 5000 1000 100
WF.536/.615 Wide Flange Plastic End Plugs - WIDER FLANGE TAPERED PLUG CAP, LDPE
13.6
0.536
15.6
0.615
12.0
0.474
14.0
0.553
11.2
0.440
23.9
0.940
 5000 1000 100
WF.590/.670 Plastic End Caps with Wider Brim - WIDER FLANGE TAPERED PLUG CAP, LDPE
15.0
0.590
17.0
0.670
13.4
0.528
15.4
0.608
12.7
0.500
25.4
1.000
 5000 1000 100
WF.643/.726 Plastic Stoppers with Wide Flange - WIDER FLANGE TAPERED PLUG CAP, LDPE
16.3
0.643
18.4
0.726
14.8
0.581
16.8
0.662
12.7
0.500
26.2
1.030
 5000 1000 100
WF.683/.785 Wide Flange Tapered Plastic Plug Caps - WIDER FLANGE TAPERED PLUG CAP, LDPE
17.3
0.683
19.9
0.785
15.8
0.621
18.4
0.723
13.5
0.530
28.7
1.130
 5000 1000 100
WF.765/.865 Wide Flange Plastic End Plugs - WIDER FLANGE TAPERED PLUG CAP, LDPE
19.4
0.765
22.0
0.865
17.9
0.703
20.4
0.803
14.2
0.560
30.2
1.190
 5000 1000 100
WF.820/.930 Plastic End Caps with Wider Brim - WIDER FLANGE TAPERED PLUG CAP, LDPE
20.8
0.820
23.6
0.930
19.3
0.758
22.0
0.868
15.0
0.590
31.8
1.250
 5000 1000 100
WF.872/.977 Plastic Stoppers with Wide Flange - WIDER FLANGE TAPERED PLUG CAP, LDPE
22.1
0.872
24.8
0.977
20.6
0.810
23.3
0.916
15.0
0.590
33.3
1.310
 2500 500 50
WF.975/1.10 Wide Flange Plastic Hole Stoppers - WIDER FLANGE TAPERED PLUG CAP, LDPE
24.8
0.975
28.0
1.104
23.2
0.913
26.5
1.042
18.3
0.720
36.6
1.440
 2500 500 50
WF1.15/1.27 Wide Flange Tapered Plastic Plug Caps - WIDER FLANGE TAPERED PLUG CAP, LDPE
29.4
1.158
32.4
1.275
27.8
1.096
30.8
1.213
18.3
0.720
39.6
1.560
 2500 500 50
WF1.17/1.28 Wide Flange Plastic End Plugs - WIDER FLANGE TAPERED PLUG CAP, LDPE
29.8
1.175
32.6
1.284
28.4
1.120
31.2
1.229
16.0
0.630
42.4
1.670
 2500 500 50
WF1.24/1.37 Plastic End Caps with Wider Brim - WIDER FLANGE TAPERED PLUG CAP, LDPE
31.6
1.243
34.9
1.375
30.0
1.181
33.4
1.313
18.3
0.720
42.9
1.690
 2500 500 50
WF1.31/1.47 Plastic Stoppers with Wide Flange - WIDER FLANGE TAPERED PLUG CAP, LDPE
33.3
1.312
37.5
1.475
31.8
1.250
35.9
1.413
22.4
0.880
46.0
1.810
 1000 200 20
WF1.45/1.61 Wide Flange Tapered Plastic Plug Caps - WIDER FLANGE TAPERED PLUG CAP, LDPE
37.0
1.455
41.0
1.615
35.4
1.393
39.4
1.553
18.3
0.720
49.3
1.940
 1000 200 20
WF1.51/1.60 Wide Flange Plastic End Plugs - WIDER FLANGE TAPERED PLUG CAP, LDPE
38.5
1.517
40.6
1.600
36.4
1.432
38.5
1.514
12.4
0.490
57.4
2.260
 2000 400 40
WF1.57/1.68 Plastic End Caps with Wider Brim - WIDER FLANGE TAPERED PLUG CAP, LDPE
40.0
1.575
42.8
1.685
38.4
1.513
41.2
1.623
17.5
0.690
50.8
2.000
 1000 200 20
WF1.73/1.90 Plastic Stoppers with Wide Flange - WIDER FLANGE TAPERED PLUG CAP, LDPE
44.1
1.735
48.3
1.900
42.5
1.673
46.7
1.838
18.3
0.720
56.4
2.220
 1000 200 20
WF1.81/1.95 Wide Flange Plastic Hole Stoppers - WIDER FLANGE TAPERED PLUG CAP, LDPE
46.0
1.810
49.5
1.950
44.4
1.748
48.0
1.888
17.5
0.690
58.7
2.310
 1000 200 20
WF1.94/2.10 Wide Flange Tapered Plastic Plug Caps - WIDER FLANGE TAPERED PLUG CAP, LDPE
49.4
1.945
53.3
2.100
47.8
1.883
51.8
2.038
17.5
0.690
62.0
2.440
 1000 200 20
Part # Description Small O.D.
mm
in
 Large O.D.
mm
in
 Small I.D.
mm
in
 Large I.D.
mm
in
 Length
mm
in
 Flange OD
mm
in
 Box/Mini/Micro
QTY		 See Prices / Buy Online
Legend:
- Add to Basket - View Price

PlugTo use as a PLUG:
Select a PLUG with a “B” dimension at least 0.5mm (.020” ) larger than the diameter to be plugged (increase 1% or more for large diameters)

Cap To use as a CAP:
Select a CAP with a “C” dimension at least 0.5mm (.020” ) smaller than the diameter to be capped (increase 1% or more for large diameters)

Micropacks are only available for purchase through our online store.



Not sure what part you need? Would you like to consider another type or part, or a different material?
Consult MOCAP's Application Advisor for assistance.



Wide Flange Tapered Plastic Plug Caps - Information

MOCAP Wide Flange Tapered Plastic Plug Caps are inexpensive dual function closures which can be used as either a plug or a cap. These tapered polyethylene plug caps are made from tough, but flexible polyethylene to form a secure fit, yet are easily removed.
These Plastic Plugs feature a wider flange than our standard T Series plug caps, adding protection for external surfaces and preventing the plug from accidentally being pushed all the way into or through an opening.
Recommended to use as a cap for tube and hydraulic fittings, tube end caps, pipe caps or product protection. Or use as a plug for threaded holes, openings, fittings and ports.

  • Durable and Flexible - Use as a Cap or Plug
  • Protects Against Debris, Damage, Moisture and Corrosion
  • Many Sizes of Our Wide Flange Tapered Plastic Plug Caps are Stocked for Immediate Shipment.



Functions as a Cap
MOCAP WF Series Plastic Plug Caps have a tapered design which allow it to be used as a cap for multiple threaded and non-threaded applications.
Review MOCAP's Selection of Caps.

Functions as a Plug
Use MOCAP Tapered Plug Caps to plug a wide range of openings, including threaded and non-threaded holes, pipe and tube end plugs, connector ports and fittings.
Review MOCAP's Selection of Plugs.

Masking Applications
MOCAP Plug Caps can also be used as inexpensive, single use disposable masking caps or masking plugs for painting, coating and spraying processes up to 175°F(79°C).
Review MOCAP's complete Line of Masking Products.

Many Sizes of Our Wide Flange Tapered Plastic Plug Caps are Stocked for Immediate Shipment.



Most stock sizes are available in Mini-Packs when Smaller Quantities are Needed. To place an order for this product, call 0800 046 7436 or use our Contact Request Form to receive information by e-mail.
