  • Material: Vinyl
  • Flexible Yet Durable - Won't Split, Tear or Shred
  • Wide Flange for Easy Removal
  • Stretches for a Snug Fit but Won't Split, Tear or Shred

Size Chart Flexible Vinyl Tube Plug

CMCP Size Chart

Table View
List View
Part # Description To Fit METRIC Thread To Fit STD Thread To Fit NPT Flange OD
mm
in
Box/Mini/Micro
QTY
See Prices / Buy Online
CMCP05S UK Vinyl Plastic Plugs CMCP05S M6 1/4
10.2
0.400
2574 514 51
CMCP1S UK Rubber End Plugs CMCP1S M8 5/16
11.7
0.460
2574 514 51
CMCP2S UK Plastic End Plugs CMCP2S M10 3/8 1/8
12.6
0.495
2640 528 52
CMCP25S UK Vinyl Tube End Plugs CMCP25S M12 7/16
14.0
0.550
2646 529 52
CMCP3S UK Rubber hole plugs CMCP3S M14 1/2 1/4
15.7
0.620
2700 540 54
CMCP35S UK Rubber Insertion Plugs CMCP35S M16 9/16
17.3
0.683
2544 508 50
CMCP4S UK Vinyl Insertion Plugs CMCP4S M18 5/8 3/8
20.5
0.807
2560 512 51
CMCP5S UK Flexible Vinyl Tube Plug CMCP5S M20 3/4 1/2
24.4
0.961
2592 518 51
CMCP55S UK Flexible Plastic Stopper CMCP55S M22, M24 7/8
26.9
1.058
1344 268 26
CMCP6S UK Vinyl Plastic Plugs CMCP6S M26, M28 1-1/16 3/4
31.6
1.245
1320 264 26
CMCP7S UK Rubber End Plugs CMCP7S M32, M34 1-1/8, 1-3/16, 1-1/4 1
38.0
1.495
1377 275 27
Part # Description To Fit METRIC Thread To Fit STD Thread To Fit NPT Flange OD
mm
in
Box/Mini/Micro
QTY
See Prices / Buy Online
Legend:
- Add to Basket - View Price

NOTE: Due to the inherent variability of the dip-molding process, the "Flange OD" may vary by +/-1.6mm (1/16") from the figures shown above.

Wall thickness is measured approx. 6.35mm (.25 inch) from open end. Wall thickness increases slightly towards the closed end of the part

Micropacks are only available for purchase through our online store.



Not sure what part you need? Would you like to consider another type or part, or a different material?
Consult MOCAP's Application Advisor for assistance.



Vinyl Plastic Plugs - Information

MOCAP Vinyl Plastic Plugs are perfect for shipping, masking and thread protectors. Use these plastic plugs to protect valves, pumps, cylinders, tubing and other applications.

Flexible plastic plugs compress within holes to form a snug fit that keeps dust, debris and contaminants out. Plastic plugs have a wide flange for easy install and removal. Use MOCAP plastic plug as pipe plug, hole plug, masking plug or lower cost alternative to rubber plug.

MOCAP round vinyl plastic plugs are available in sizes to fit 1/4" through 1-1/4" satndard threaded holes, M6 through M40 metric openings and 1/2 through 1 NPT openings.

Product Protection
Use our vinyl plastic plugs as durable and inexpensive plugs to protect your product during assembly or shipping.

Masking Applications
MOCAP vinyl plastic plugs are often used as inexpensive and disposable single use masking plugs for painting and coating processes under 212°F(100°C). For higher temperatures, consider our High Temperature Vinyl good to 446°F(230°C), EPDM Masking Products good to 300°F(149°C), or our Silicone Masking Products good to over 600°F(316°C).




RoHS


Diagram
