Sealing Plugs for Unified/Straight Threads

SPU


UNF Sealing Plugs with Slotted Hex Head
Sealing Plugs for Unified/Straight Threads

SPU – Product Media

Sealing Plugs for Unified/Straight Threads Plastic Sealing Plugs for UNF Threads UNF Sealing Plug Caps (Polypropylene or Nylon) Plastic Sealing Bolt for UNF Threads Sealing Plugs for Unified/Straight Threads UNF Sealing Plugs with Slotted Hex Head Plastic Sealing Plugs for UNF Threads UNF Sealing Plug Caps (Polypropylene or Nylon) Plastic Sealing Bolt for UNF Threads Sealing Plugs for Unified/Straight Threads
  • Material: PP (Polypropylene) (Red), Nylon (Yellow)
  • Designed with Five Complete Threads Plus an Integrated Sealing Lip for a Tight Fit
  • Also Available with a Factory Fit Neoprene O-Ring when a Secure Seal is Required
Select your item

Size Chart UNF Sealing Plug Caps (Polypropylene or Nylon)

PrintPrint

SPU Size Chart

Part # Description O-Ring To Fit STD Thread Flange OD
mm
in
Stem Height
mm
in
Length
mm
in
Colour Box/Mini/Micro
QTY
See Prices / Buy Online
SPU0437-20RD4 Sealing Plugs for Unified/Straight Threads - SEALING PLUG FOR 7/16-20 PORT, PP RED 7/16 - 20
20.8
0.820
8.9
0.350
10.9
0.430
Red 5000 1000 100
SPU0437-20RD4NO Plastic Sealing Bolt for UNF Threads - SEALING PLUG FOR 7/16-20 PORT, PP RED W/ORING 7/16 - 20
20.8
0.820
8.9
0.350
10.9
0.430
Red 5000 1000 100
SPU0500-20RD4 UNF Sealing Plug Caps (Polypropylene or Nylon) - SEALING PLUG FOR 1/2-20 PORT, PP RED 1/2 - 20
22.9
0.900
9.9
0.390
10.9
0.430
Red 3000 600 60
SPU0500-20RD4NO Plastic Sealing Plugs for UNF Threads - SEALING PLUG FOR 1/2-20 PORT, PP RED W/ ORING 1/2 - 20
22.9
0.900
9.9
0.390
10.9
0.430
Red 3000 600 60
SPU0562-18RD4 UNF Sealing Plugs with Slotted Hex Head - SEALING PLUG FOR 9/16-18 PORT, PP RED 9/16 - 18
24.9
0.980
9.9
0.390
10.9
0.430
Red 3000 600 60
SPU0562-18RD4NO Sealing Plugs for Unified/Straight Threads - SEALING PLUG FOR 9/16-18 PORT, PP RED W/ ORING 9/16 - 18
24.9
0.980
9.9
0.390
10.9
0.430
Red 3000 600 60
SPU0625-18RD4 Plastic Sealing Bolt for UNF Threads - SEALING PLUG FOR 5/8-18 PORT, PP RED 5/8 - 18
24.9
0.980
11.9
0.470
11.9
0.470
Red 3000 600 60
SPU0625-18RD4NO UNF Sealing Plug Caps (Polypropylene or Nylon) - SEALING PLUG FOR 5/8-18 PORT, PP RED W/ ORING 5/8 - 18
24.9
0.980
11.9
0.470
11.9
0.470
Red 3000 600 60
SPU0750-16RD4 Plastic Sealing Plugs for UNF Threads - SEALING PLUG FOR 3/4-16 PORT, PP RED 3/4 - 16
25.9
1.020
13.0
0.510
9.9
0.390
Red 3000 600 60
SPU0750-16RD4NO Sealing Plugs for Unified/Straight Threads - SEALING PLUG FOR 3/4-16 PORT, PP RED W/ ORING 3/4 - 16
25.9
1.020
13.0
0.510
9.9
0.390
Red 3000 600 60
SPU0875-14RD4 Plastic Sealing Bolt for UNF Threads - SEALING PLUG FOR 7/8-14 PORT, PP RED 7/8 - 14
33.8
1.330
11.9
0.470
14.0
0.550
Red 3000 600 60
SPU0875-14RD4NO UNF Sealing Plug Caps (Polypropylene or Nylon) - SEALING PLUG FOR 7/8-14 PORT, PP RED W/ ORING 7/8 - 14
33.8
1.330
11.9
0.470
14.0
0.550
Red 3000 600 60
SPU1062-12RD4 Plastic Sealing Plugs for UNF Threads - SEALING PLUG FOR 1-1/16-12 PORT, PP RED 1-1/16 - 12
40.9
1.610
11.9
0.470
14.0
0.550
Red 1000 200 20
SPU1062-12RD4NO UNF Sealing Plugs with Slotted Hex Head - SEALING PLUG FOR 1-1/16-12 PORT, PP RED W/ ORING 1-1/16 - 12
40.9
1.610
11.9
0.470
14.0
0.550
Red 1000 200 20
SPU1313-12RD4 Sealing Plugs for Unified/Straight Threads - SEALING PLUG FOR 1-5/16-12 PORT, PP RED 1-5/16 - 12
41.9
1.650
15.0
0.590
15.0
0.590
Red 1000 200 20
SPU1313-12RD4NO Plastic Sealing Bolt for UNF Threads - SEALING PLUG FOR 1-5/16-12 PORT, PP RED W/ ORING 1-5/16 - 12
41.9
1.650
15.0
0.590
15.0
0.590
Red 1000 200 20
SPU1625-12RD4 UNF Sealing Plug Caps (Polypropylene or Nylon) - SEALING PLUG FOR 1-5/8-12 PORT, PP RED 1-5/8 - 12
57.9
2.280
15.0
0.590
17.0
0.670
Red 500 100 10
SPU1625-12RD4NO Plastic Sealing Plugs for UNF Threads - SEALING PLUG FOR 1-5/8-12 PORT, PP RED W/ ORING 1-5/8 - 12
57.9
2.280
15.0
0.590
17.0
0.670
Red 500 100 10
SPU0437-20YW5 Sealing Plugs for Unified/Straight Threads - SEALING PLUG FOR 7/16-20 PORT, NYLON YELLOW 7/16 - 20
20.8
0.820
8.9
0.350
10.9
0.430
Yellow 5000 1000 100
SPU0437-20YW5NO Plastic Sealing Bolt for UNF Threads - SEALING PLUG FOR 7/16-20 PORT, NYLON YELLOW W/ ORING 7/16 - 20
20.8
0.820
8.9
0.350
10.9
0.430
Yellow 5000 1000 100
SPU0500-20YW5 UNF Sealing Plug Caps (Polypropylene or Nylon) - SEALING PLUG FOR 1/2-20 PORT, NYLON YELLOW 1/2 - 20
22.9
0.900
9.9
0.390
10.9
0.430
Yellow 3000 600 60
SPU0500-20YW5NO Plastic Sealing Plugs for UNF Threads - SEALING PLUG FOR 1/2-20 PORT, NYLON YELLOW W/ ORING 1/2 - 20
22.9
0.900
9.9
0.390
10.9
0.430
Yellow 3000 600 60
SPU0562-18YW5 UNF Sealing Plugs with Slotted Hex Head - SEALING PLUG FOR 9/16-18 PORT, NYLON YELLOW 9/16 - 18
24.9
0.980
9.9
0.390
10.9
0.430
Yellow 3000 600 60
SPU0562-18YW5NO Sealing Plugs for Unified/Straight Threads - SEALING PLUG FOR 9/16-18 PORT, NYLON YELLOW W/ ORING 9/16 - 18
24.9
0.980
9.9
0.390
10.9
0.430
Yellow 3000 600 60
SPU0625-18YW5 Plastic Sealing Bolt for UNF Threads - SEALING PLUG FOR 5/8-18 PORT, NYLON YELLOW 5/8 - 18
24.9
0.980
11.9
0.470
11.9
0.470
Yellow 3000 600 60
SPU0625-18YW5NO UNF Sealing Plug Caps (Polypropylene or Nylon) - SEALING PLUG FOR 5/8-18 PORT, NYLON YELLOW W/ ORING 5/8 - 18
24.9
0.980
11.9
0.470
11.9
0.470
Yellow 3000 600 60
SPU0750-16YW5 Plastic Sealing Plugs for UNF Threads - SEALING PLUG FOR 3/4-16 PORT, NYLON YELLOW 3/4 - 16
25.9
1.020
13.0
0.510
9.9
0.390
Yellow 3000 600 60
SPU0750-16YW5NO Sealing Plugs for Unified/Straight Threads - SEALING PLUG FOR 3/4-16 PORT, NYLON YELLOW W/ ORING 3/4 - 16
25.9
1.020
13.0
0.510
9.9
0.390
Yellow 3000 600 60
SPU0875-14YW5 Plastic Sealing Bolt for UNF Threads - SEALING PLUG FOR 7/8-14 PORT, NYLON YELLOW 7/8 - 14
33.8
1.330
11.9
0.470
14.0
0.550
Yellow 3000 600 60
SPU0875-14YW5NO UNF Sealing Plug Caps (Polypropylene or Nylon) - SEALING PLUG FOR 7/8-14 PORT, NYLON YELLOW W/ ORING 7/8 - 14
33.8
1.330
11.9
0.470
14.0
0.550
Yellow 3000 600 60
SPU1062-12YW5 Plastic Sealing Plugs for UNF Threads - SEALING PLUG FOR 1-1/16-12 PORT, NYLON YELLOW 1-1/16 - 12
40.9
1.610
11.9
0.470
14.0
0.550
Yellow 1000 200 20
SPU1062-12YW5NO UNF Sealing Plugs with Slotted Hex Head - SEALING PLUG FOR 1-1/16-12 PORT, NYLON YELLOW W/ ORING 1-1/16 - 12
40.9
1.610
11.9
0.470
14.0
0.550
Yellow 1000 200 20
SPU1313-12YW5 Sealing Plugs for Unified/Straight Threads - SEALING PLUG FOR 1-5/16-12 PORT, NYLON YELLOW 1-5/16 - 12
41.9
1.650
15.0
0.590
15.0
0.590
Yellow 1000 200 20
SPU1313-12YW5NO Plastic Sealing Bolt for UNF Threads - SEALING PLUG FOR 1-5/16-12 PORT, NYLON YELLOW W/ ORING 1-5/16 - 12
41.9
1.650
15.0
0.590
15.0
0.590
Yellow 1000 200 20
SPU1625-12YW5 UNF Sealing Plug Caps (Polypropylene or Nylon) - SEALING PLUG FOR 1-5/8-12 PORT, NYLON YELLOW 1-5/8 - 12
57.9
2.280
15.0
0.590
17.0
0.670
Yellow 500 100 10
SPU1625-12YW5NO Plastic Sealing Plugs for UNF Threads - SEALING PLUG FOR 1-5/8-12 PORT, NYLON YELLOW W/ ORING 1-5/8 - 12
57.9
2.280
15.0
0.590
17.0
0.670
Yellow 500 100 10
Part # Description O-Ring To Fit STD Thread Flange OD
mm
in
Stem Height
mm
in
Length
mm
in
Colour Box/Mini/Micro
QTY
See Prices / Buy Online
Legend:
- Add to Basket - View Price

Micropacks are only available for purchase through our online store.



Not sure what part you need? Would you like to consider another type or part, or a different material?
Consult MOCAP's Application Advisor for assistance.



Sealing Plugs for Unified/Straight Threads - Information

MOCAP Sealing Plugs for Unified/Straight Threads are designed to protect Unified/Straight-threaded ports and fittings from moisture, dust and damage during production, shipping and storage. Five complete threads plus a sealing lip provide a tight fit and secure seal. Can be applied and removed by hand, with a socket wrench, screwdriver or power tool.

Our SPU Series Plugs are:


  • Moulded in Red Polypropylene (Standard applications) or
  • Yellow Nylon (offers high resistance against hydraulic fluids, solvents, acids and base alkalines)
  • Sized to fit Unified/Straight Threads from 7/16-20 thru 1-5/8-12.

These Sealing Plugs are also available with a factory-fit Neoprene Rubber O-Ring when a perfect seal is required.

MOCAP stocks Sealing Plugs for Unified/Straight Threads in both Red Polypropylene and Yellow Nylon materials in many sizes for immediate shipment.

Most stock sizes are available in Mini-Packs when Smaller Quantities are Needed. To place an order for this product, call 0800 856 2466 or use our Contact Request Form to receive information by e-mail.
