Split Hydraulic Flange Plugs

SHF


Plugs for Four-Bolt Split Hydraulic Flanges
Split Hydraulic Flange Plugs

SHF–Product Media

Split Hydraulic Flange Plugs Split Hydraulic Flange Plugs Covers for Split Flange Ports Plastic Inserts for Split Flange Ports Plastic Plugs for Split Flange Connections Plugs for Four-Bolt Split Hydraulic Flanges LDPE Split Flange Port Plugs SAE 3000 lb Split Hydraulic Flanges Split Flange Plugs Split Hydraulic Flange Plugs
  • Material: LDPE (Low Density Polyethylene)
  • Stocked Material: LDPE (Red)
  • Intended for Use on SAE 3000 LB, Four-bolt Split Hydraulic Flanges
  • Designed to Protect the Port, Flange Surface and Bolt Holes from Damage and Debris

Size Chart Covers for Split Flange Ports

SHF Size Chart

Table View
List View
Part # Description To Fit Flange Size To Fit Dash Size Small O.D.
mm
in
 Large O.D.
mm
in
 Flange Width
mm
in
 Flange Height
mm
in
 Length
mm
in
 Box/Mini/Micro
QTY		 See Prices / Buy Online
SHF.750 Split Hydraulic Flange Plugs - PLUG FOR 3/4"-12 SPLIT HYDRAULIC FLANGE 3/4” 12
18.5
0.730
20.1
0.790
65.0
2.560
41.1
1.620
12.7
0.500
 2500 500 50
SHF1.000 Split Flange Plugs - PLUG FOR 1"-16 SPLIT HYDRAULIC FLANGE 1 ” 16
24.9
0.980
26.4
1.040
69.9
2.750
47.8
1.880
12.7
0.500
 1000 200 20
SHF1.250 SAE 3000 lb Split Hydraulic Flanges - PLUG FOR 1-1/4"-20 SPLIT HYDRAULIC FLANGE 1-1/4” 20
31.2
1.230
32.8
1.290
79.2
3.120
50.8
2.000
12.7
0.500
 1000 200 20
SHF1.500 LDPE Split Flange Port Plugs - PLUG FOR 1-1/2"-24 SPLIT HYDRAULIC FLANGE 1-1/2” 24
37.1
1.460
39.4
1.550
93.7
3.690
60.5
2.380
19.1
0.750
 500 100 10
SHF2.000 Plugs for Four-Bolt Split Hydraulic Flanges - PLUG FOR 2"-32 SPLIT HYDRAULIC FLANGE 2 ” 32
49.8
1.960
52.1
2.050
101.6
4.000
69.9
2.750
19.1
0.750
 500 100 10
SHF2.500 Plastic Plugs for Split Flange Connections - PLUG FOR 2-1/2"-40 SPLIT HYDRAULIC FLANGE 2-1/2” 40
62.5
2.460
64.8
2.550
114.3
4.500
82.6
3.250
19.1
0.750
 250 50 5
Part # Description To Fit Flange Size To Fit Dash Size Small O.D.
mm
in
 Large O.D.
mm
in
 Flange Width
mm
in
 Flange Height
mm
in
 Length
mm
in
 Box/Mini/Micro
QTY		 See Prices / Buy Online
Legend:
- Add to Basket - View Price

Micropacks are only available for purchase through our online store.



Not sure what part you need? Would you like to consider another type or part, or a different material?
Consult MOCAP's Application Advisor for assistance.



Split Hydraulic Flange Plugs - Information

MOCAP Split Hydraulic Flange Plugs are designed for use on SAE 3000 lb., four-bolt split hydraulic flanges allowing for maximum flexibility. Designed to protect the port, flange surface and bolt holes from damage and debris during transit, handling and storage, our SHF series Split Hydraulic Flange Plugs are easy to install and remove.

Our SHF Series parts are molded in red LDPE plastic to fit 3/4-12 thru 2-1/2-40 Nominal Flange sizes.

Many Sizes of Our Split Hydraulic Flange Plugs are Stocked for Immediate Shipment.


Most stock sizes are available in Mini-Packs when Smaller Quantities are Needed. To place an order for this product, call 0800 046 7436 or use our Contact Request Form to receive information by e-mail.







RoHS


Diagram
