Tear Tab Plastic Caps for Straight Threads

TCS


Polyethylene Tear Caps for Straight Threads
Tear Tab Plastic Caps for Straight Threads

TCS – Product Media

Tear Caps for Straight Threads Tear away plastic cap for Straight Threads Removalble Plastic Caps for Straight Threads with Tear Tab Plastic Tear Caps for Straight Threads Tear Tab Plastic Caps for Straight Threads Polyethylene Tear Caps for Straight Threads Tear away plastic cap for Straight Threads Removalble Plastic Caps for Straight Threads with Tear Tab Plastic Tear Caps for Straight Threads
  • Material: LDPE (Low Density Polyethylene)
  • Stocked Material: LDPE (Red)
  • Secure Fit Until Removed by Pulling Tab and Breaking Seal
  • Use as Shipping Cap, End Cap or Thread Protector

Size Chart Removalble Plastic Caps for Straight Threads with Tear Tab

PrintPrint

TCS Size Chart

Part # Description To Fit STD Thread Inside Diameter
mm
in
Inside Length
mm
in
See Prices / Buy Online
TCS0375 Tear Tab Plastic Caps for Straight Threads - TEAR CAP FOR 0.1875" (3/16") TUBE OR 0.375" (3/8") STR THRDS 3/8 - 24
9.4
0.371
11.2
0.440
TCS0437 Plastic Tear Caps for Straight Threads - TEAR CAP FOR 0.250" (1/4") TUBE OR 0.4375" (7/16") STR THRDS 7/16 - 20
10.9
0.428
11.2
0.440
TCS0500 Removalble Plastic Caps for Straight Threads with Tear Tab - TEAR CAP FOR 0.3125" (5/16") TUBE OR 0.500" (1/2") STR THRDS 1/2 - 20
12.6
0.495
11.7
0.460
TCS0562 Tear away plastic cap for Straight Threads - TEAR CAP FOR 0.375" (3/8") TUBE OR 0.5625" (9/16") STR THRDS 9/16 - 20
14.2
0.559
12.2
0.480
TCS0625 Polyethylene Tear Caps for Straight Threads - TEAR CAP FOR 0.375" (3/8") TUBE OR 0.625 (5/8") STR THRDS 5/8 - 18
15.6
0.615
12.2
0.480
TCS0687 Tear Tab Plastic Caps for Straight Threads - TEAR CAP FOR 0.375" (3/8") TUBE OR 0.6875" (11/16")STR THRDS 11/16 - 16
17.3
0.680
12.2
0.480
TCS0750 Plastic Tear Caps for Straight Threads - TEAR CAP FOR 0.500" (1/2") TUBE OR 0.750" (3/4") STR THRDS 3/4 - 16
18.8
0.740
14.2
0.560
TCS0812 Removalble Plastic Caps for Straight Threads with Tear Tab - TEAR CAP FOR 0.500" (1/2") TUBE OR 0.8125" (13/16") STR THRD 13/16 - 12
20.4
0.803
16.3
0.640
TCS0875 Tear away plastic cap for Straight Threads - TEAR CAP FOR 0.625" (5/8") TUBE OR 0.875" (7/8") STR THRDS 7/8 - 14
22.0
0.865
17.8
0.700
TCS1000 Tear Tab Plastic Caps for Straight Threads - TEAR CAP FOR 0.625" (5/8") TUBE OR 1.000" (1") STR THRDS 1 - 14
25.2
0.993
16.5
0.650
TCS1062 Plastic Tear Caps for Straight Threads - TEAR CAP FOR 0.750" (3/4") TUBE OR 1.0625" (1-1/16") STR THR 1-1/16 - 12
26.7
1.053
21.1
0.830
TCS1187 Removalble Plastic Caps for Straight Threads with Tear Tab - TEAR CAP FOR 0.875" (7/8") TUBE OR 1.1875" (1-3/16") STR THR 1-3/16 - 12
30.0
1.180
19.1
0.750
TCS1312 Tear away plastic cap for Straight Threads - TEAR CAP FOR 1.000" (1") TUBE OR 1.3125" (1-5/16") STR THRDS 1-5/16 - 12
33.1
1.305
19.1
0.750
TCS1437 Polyethylene Tear Caps for Straight Threads - TEAR CAP FOR 1.000" (1") TUBE OR 1.4375" (1-7/16") STR THRDS 1-7/16 - 12
36.3
1.430
19.1
0.750
Part # Description To Fit STD Thread Inside Diameter
mm
in
Inside Length
mm
in
See Prices / Buy Online
Legend:
- Add to Basket - View Price

 Tear Tab makes REMOVAL EASY:
Pull the tab up to easily break the seal and the CAP comes right off!



Not sure what part you need? Would you like to consider another type or part, or a different material?
Consult MOCAP's Application Advisor for assistance.



Tear Tab Plastic Caps for Straight Threads - Information

MOCAP TCS Series Tear Tab Plastic Caps are designed to fit over threaded tubing, rods and fittings with straight threads.
These plastic caps are ideal for use as shipping caps, end caps, pipe caps, product protection and thread protectors. Inner rings lock cap securely onto threads until the cap is removed by pulling the easy grip tab and breaking the seal.

TCS Series Tear Tab Plastic Caps in sizes to fit 3/16" through 1" tubes.

Additional series of tear tab plastic caps available to fit Metric, BSP and NPT Threads and fittings.

  • Secure Fit Until Removed by Pulling Tab and Breaking Seal
  • Use as End Cap, Shipping Cap or Thread Protector
  • Sizes Available to Fit Metric, BSP and NPT Threads



Many Sizes of Our Tear Tab Plastic Caps for Straight Threads are Stocked for Immediate Shipment.


Most stock sizes are available in Mini-Packs when Smaller Quantities are Needed. To place an order for this product, call 0800 046 7436 or use our Contact Request Form to receive information by e-mail.








RoHS
