Center Pull Plugs with Wide Flanges

CPW


Plastic Center Pull Plugs
Center Pull Plugs with Wide Flanges

CPW – Product Media

Center Pull Plugs with Wide Flanges Wide Flange Center Pull Tab Plugs Plastic Center Pull Plugs  with Wide Brim Tapered Center Pull Plugs Center Pull Plugs with Wide Flanges Plastic Center Pull Plugs Wide Flange Center Pull Tab Plugs Plastic Center Pull Plugs  with Wide Brim Tapered Center Pull Plugs Center Pull Plugs with Wide Flanges
  • Material: LDPE (Red)
  • Center Pull Tab Allows for Quick and Easy Removal
  • Extra Strong Tab is Moulded into Plug so it Will Not Break Off
  • Featuring a Wider Flange than the CP Series for Added Protection of External Surfaces
Select your item

Size Chart Plastic Center Pull Plugs with Wide Brim

PrintPrint

CPW Size Chart

Part # Description Small O.D.
mm
in
Large O.D.
mm
in
Flange OD
mm
in
Length
mm
in
Tab Height
mm
in
Tab Width
mm
in
Box/Mini/Micro
QTY
See Prices / Buy Online
CPW.48/.54RD1 Center Pull Plugs with Wide Flanges - CENTER PULL WIDE FLANGE LDPE RED
12.2
0.480
13.7
0.540
31.8
1.250
13.5
0.530
6.4
0.250
9.5
0.375
5000 1000 100
CPW.59/.65RD1 Tapered Center Pull Plugs - CENTER PULL WIDE FLANGE LDPE RED
15.0
0.590
16.4
0.647
26.9
1.060
12.7
0.500
6.4
0.250
9.5
0.375
5000 1000 100
CPW.73/.79RD1 Plastic Center Pull Plugs with Wide Brim - CENTER PULL WIDE FLANGE LDPE RED
18.5
0.730
20.1
0.790
38.1
1.500
12.7
0.500
6.4
0.250
15.9
0.625
3000 600 60
CPW.75/.85RD1 Wide Flange Center Pull Tab Plugs - CENTER PULL WIDE FLANGE LDPE RED
19.1
0.752
21.6
0.849
33.3
1.310
12.7
0.500
6.4
0.250
15.9
0.625
2500 500 50
CPW.92/1.08RD1 Plastic Center Pull Plugs - CENTER PULL WIDE FLANGE LDPE RED
23.4
0.921
27.3
1.075
41.1
1.620
19.1
0.750
6.4
0.250
15.9
0.625
1500 300 30
CPW.98/1.04RD1 Center Pull Plugs with Wide Flanges - CENTER PULL WIDE FLANGE LDPE RED
24.9
0.980
26.4
1.040
47.8
1.880
13.5
0.530
6.4
0.250
15.9
0.625
1500 300 30
CPW1.07/1.19RD1 Tapered Center Pull Plugs - CENTER PULL WIDE FLANGE LDPE RED
27.2
1.069
30.2
1.188
43.9
1.730
17.5
0.690
6.4
0.250
25.4
1.000
1000 200 20
CPW1.20/1.30RD1 Plastic Center Pull Plugs with Wide Brim - CENTER PULL WIDE FLANGE LDPE RED
30.5
1.202
32.9
1.297
47.8
1.880
19.1
0.750
6.4
0.250
25.4
1.000
1000 200 20
CPW1.23/1.29RD1 Wide Flange Center Pull Tab Plugs - CENTER PULL WIDE FLANGE LDPE RED
31.2
1.230
32.8
1.290
50.8
2.000
12.7
0.500
6.4
0.250
25.4
1.000
1200 240 24
CPW1.46/1.55RD1 Center Pull Plugs with Wide Flanges - CENTER PULL WIDE FLANGE LDPE RED
37.1
1.460
39.4
1.550
60.5
2.380
19.1
0.750
6.4
0.250
25.4
1.000
500 100 10
CPW1.52/1.60RD1 Tapered Center Pull Plugs - CENTER PULL WIDE FLANGE LDPE RED
38.6
1.519
40.7
1.602
57.2
2.250
19.1
0.750
6.4
0.250
25.4
1.000
500 100 10
CPW1.81/1.93RD1 Plastic Center Pull Plugs with Wide Brim - CENTER PULL WIDE FLANGE LDPE RED
45.9
1.807
49.1
1.932
64.3
2.530
19.1
0.750
6.4
0.250
25.4
1.000
500 100 10
CPW1.96/2.05RD1 Wide Flange Center Pull Tab Plugs - CENTER PULL WIDE FLANGE LDPE RED
49.8
1.960
52.1
2.050
69.9
2.750
19.1
0.750
6.4
0.250
25.4
1.000
500 100 10
CPW2.46/2.55RD1 Plastic Center Pull Plugs - CENTER PULL WIDE FLANGE LDPE RED
62.5
2.460
64.8
2.550
82.6
3.250
19.1
0.750
6.4
0.250
25.4
1.000
250 50 5
Part # Description Small O.D.
mm
in
Large O.D.
mm
in
Flange OD
mm
in
Length
mm
in
Tab Height
mm
in
Tab Width
mm
in
Box/Mini/Micro
QTY
See Prices / Buy Online
Legend:
- Add to Basket - View Price

Micropacks are only available for purchase through our online store.



Not sure what part you need? Would you like to consider another type or part, or a different material?
Consult MOCAP's Application Advisor for assistance.



Center Pull Plugs with Wide Flanges - Information

MOCAP Center Pull Tapered Plastic Plugs with Wide Flanges are similar to our Center Pull Plugs, but have a wider flange designed to protect greater surface area. An extra strong tab is moulded into the bottom and sides of this plastic plug and extends well above the plug flange making it easy to grasp and remove.
  • Center Pull Tab for Easy Removal
  • Tapered Plastic Plug fits Multiple Size Openings

Many Sizes of Our Center Pull Plugs with Wide Flanges are Stocked for Immediate Shipment.


Most stock sizes are available in Mini-Packs when Smaller Quantities are Needed. To place an order for this product, call 0800 856 2466 or use our Contact Request Form to receive information by e-mail.
