Paper Straight Caps

MPSC


Inexpensive Paper Straight Caps
Paper Straight Caps

MPSC–Product Media

Paper Straight Caps Paper Masking Products Environmentally friendly paper caps Paper Straight Caps Paper Protection Caps Inexpensive Paper Straight Caps Straight Paper Caps High-Temperature Paper Straight End Cap Paper End Caps Paper Straight Caps
  • Material: Paper
  • Environmentally Friendly and Economical Masking Solution
  • Does Not Promote Condensation

Size Chart Environmentally friendly paper caps

MPSC Size Chart

Table View
List View
Part # Description To Fit MALE NPT To Fit Tube Size To Fit STD Thread To Fit Flared Tube Fitting To Fit METRIC Thread To Fit BSP Inside Diameter
mm
in
Inside Length
mm
in
Box/Mini/Micro
QTY
See Prices / Buy Online
MPSC001 Paper Straight Caps - STRAIGHT CAP, PAPER - TAN 5/16 1/4, 5/16 1/8 M8, M9 G1/8
7.7
0.303
9.4
0.370
22000 1000 100
MPSC003 Paper End Caps - STRAIGHT CAP, PAPER TAN 1/8 3/8 3/8, 7/16 3/16 M10,M11 G1/8
9.0
0.354
9.5
0.374
25000 1000 100
MPSC004 High-Temperature Paper Straight End Cap - STRAIGHT CAP, PAPER - TAN 1/8 7/16 7/16, 1/2 1/4 M11,M12
10.6
0.417
11.5
0.453
18000 1000 100
MPSC005 Straight Paper Caps - STRAIGHT CAP, PAPER - TAN 1/4 1/2 1/2, 9/16 5/16 M14,M15 G1/4
11.9
0.469
13.0
0.512
12500 1000 100
MPSC006 Inexpensive Paper Straight Caps - STRAIGHT CAP, PAPER - TAN 3/8 5/8 5/8, 11/16 3/8 M16, M17,M18 G3/8
15.2
0.598
13.4
0.528
8000 1000 100
MPSC007 Paper Protection Caps - STRAIGHT CAP, PAPER - TAN 1/2 3/4 3/4, 13/16 1/2 M20 G1/2
18.2
0.717
17.1
0.673
8500 1000 100
MPSC009 Paper Straight Caps - STRAIGHT CAP, PAPER - TAN 7/8 7/8, 15/16 5/8 M22 G5/8
20.6
0.811
20.9
0.823
5500 1000 100
MPSC010 Environmentally friendly paper caps - STRAIGHT CAP, PAPER - TAN 3/4 1 1, 1-1/16 3/4 M25, M26, M27 G3/4
24.3
0.957
21.9
0.862
4000 800 80
MPSC011 Paper Masking Products - STRAIGHT CAP, PAPER - TAN 1 1-5/16 1-1/4, 1-5/16 1 M32, M33 G1
30.6
1.205
25.3
0.996
3400 680 68
MPSC013 Paper Straight Caps - STRAIGHT CAP, PAPER - TAN 1-1/4 1-5/8 1-9/16, 1-5/8 1-1/4 M40, M42 G1-1/4
39.2
1.543
30.4
1.197
1800 360 36
MPSC016 Paper End Caps - STRAIGHT CAP, PAPER - TAN 1-7/8 1-7/8 1-1/2 M48 G1-1/2
46.4
1.827
23.2
0.913
1800 360 36
Part # Description To Fit MALE NPT To Fit Tube Size To Fit STD Thread To Fit Flared Tube Fitting To Fit METRIC Thread To Fit BSP Inside Diameter
mm
in
Inside Length
mm
in
Box/Mini/Micro
QTY
See Prices / Buy Online
Legend:
- Add to Basket - View Price

Micropacks are only available for purchase through our online store.



Not sure what part you need? Would you like to consider another type or part, or a different material?
Consult MOCAP's Application Advisor for assistance.

NOTE:
  • Part dimensions are typical from a measured lot. Individual pieces may vary.
  • Due to the material, this product may have minor dimensional variation due to changes in relative humidity.
  • Flange concentricity may vary.
  • Due to paper's natural structure, the product may be oblong in free state. This will generally aid in the product's retention capability.




Paper Straight Caps - Information

MOCAP Paper Straight Caps are an environmentally friendly and economical masking solution. These closures will withstand up to 400°F(204°C), making them ideal for low-to-high temperature applications. These straight paper caps do not promote condensation, and are made of recyclable paper.
Note: Due to the material, these Straight Paper Caps may have minor dimensional variation due to changes in relative humidity.
Our MPSC Series Caps are manufactured in tan paper and sized to fit 1/8 thru 1-1/2 flared tube fittings or 5/16 thru 1-7/8 tube OD's

Many Sizes of Our Paper Straight Caps are Stocked for Immediate Shipment.


Most stock sizes are available in Mini-Packs when Smaller Quantities are Needed. To place an order for this product, call 0800 046 7436 or use our Contact Request Form to receive information by e-mail.
