Thick Extra Wide Flange Tapered Plug Caps

XW


Polyethylene Plug Caps with Extra Wide Flange
Thick Extra Wide Flange Tapered Plug Caps

XW – Product Media

Thick Extra Wide Flange Plug Caps Caps with Extra Wide Flange for Hydraulic fittings and Pipes Plastic Stopers with Extra Wide Brim Thick Extra Wide Flange Plastic End Plugs Thick Extra Wide Flange Tapered Plug Caps Polyethylene Plug Caps with Extra Wide Flange Caps with Extra Wide Flange for Hydraulic fittings and Pipes Plastic Stopers with Extra Wide Brim
  • Material: LDPE (Yellow)
  • Over-Sized Flanges and High-Visibility for Pre-Assembly Operation Removal
  • Featuring a Wider Flange than the TWF Series for Added Protection of External Surfaces
Select your item

Size Chart Plastic Stopers with Extra Wide Brim

PrintPrint

XW Size Chart

Part # Description Small O.D.
mm
in
Large O.D.
mm
in
Small I.D.
mm
in
Large I.D.
mm
in
Length
mm
in
Flange OD
mm
in
Box/Mini/Micro
QTY
See Prices / Buy Online
XW.628/.725YW1 Thick Extra Wide Flange Tapered Plug Caps - XTRA WIDE FLANGE TAPERED PLUG CAP, LDPE YELLOW
16.0
0.628
18.4
0.725
14.4
0.566
16.3
0.643
11.2
0.440
56.6
2.230
1000 200 20
XW.755/.870YW1 Thick Extra Wide Flange Plastic End Plugs - XTRA WIDE FLANGE TAPERED PLUG CAP, LDPE YELLOW
19.2
0.755
22.1
0.870
17.4
0.686
20.0
0.788
12.7
0.500
60.2
2.370
1000 200 20
XW.867/.975YW1 Plastic Stopers with Extra Wide Brim - XTRA WIDE FLANGE TAPERED PLUG CAP, LDPE YELLOW
22.0
0.867
24.8
0.975
20.3
0.798
22.6
0.889
14.2
0.560
63.0
2.480
1000 200 20
XW.984/1.10YW1 Caps with Extra Wide Flange for Hydraulic fittings and Pipes - XTRA WIDE FLANGE TAPERED PLUG CAP, LDPE YELLOW
25.0
0.984
28.1
1.105
23.1
0.909
25.8
1.014
16.8
0.660
66.3
2.610
1000 200 20
XW1.11/1.25YW1 Polyethylene Plug Caps with Extra Wide Flange - XTRA WIDE FLANGE TAPERED PLUG CAP, LDPE YELLOW
28.2
1.110
31.8
1.253
26.6
1.046
29.7
1.171
16.8
0.660
69.3
2.730
500 100 10
XW1.23/1.38YW1 Thick Extra Wide Flange Tapered Plug Caps - XTRA WIDE FLANGE TAPERED PLUG CAP, LDPE YELLOW
31.4
1.237
35.1
1.382
29.7
1.171
32.8
1.291
16.8
0.660
73.2
2.880
800 160 16
XW1.31/1.46YW1 Thick Extra Wide Flange Plastic End Plugs - XTRA WIDE FLANGE TAPERED PLUG CAP, LDPE YELLOW
33.3
1.312
37.2
1.465
31.6
1.243
34.9
1.375
16.8
0.660
75.4
2.970
800 160 16
XW1.45/1.60YW1 Plastic Stopers with Extra Wide Brim - XTRA WIDE FLANGE TAPERED PLUG CAP, LDPE YELLOW
36.9
1.452
40.7
1.603
35.2
1.387
38.6
1.519
16.8
0.660
78.7
3.100
700 140 14
XW1.58/1.71YW1 Caps with Extra Wide Flange for Hydraulic fittings and Pipes - XTRA WIDE FLANGE TAPERED PLUG CAP, LDPE YELLOW
40.1
1.580
43.5
1.714
38.4
1.513
41.2
1.624
16.8
0.660
81.5
3.210
700 140 14
XW1.73/1.90YW1 Thick Extra Wide Flange Tapered Plug Caps - XTRA WIDE FLANGE TAPERED PLUG CAP, LDPE YELLOW
44.1
1.735
48.3
1.900
42.5
1.673
46.7
1.838
18.3
0.720
101.6
4.000
700 140 14
XW1.92/2.05YW1 Thick Extra Wide Flange Plastic End Plugs - XTRA WIDE FLANGE TAPERED PLUG CAP, LDPE YELLOW
48.9
1.927
52.3
2.058
47.4
1.867
50.1
1.973
16.8
0.660
90.4
3.560
600 120 12
XW2.12/2.29YW1 Plastic Stopers with Extra Wide Brim - XTRA WIDE FLANGE TAPERED PLUG CAP, LDPE YELLOW
53.8
2.120
58.2
2.290
51.7
2.036
56.1
2.210
25.4
1.000
96.3
3.790
300 60 6
XW2.39/2.60YW1 Caps with Extra Wide Flange for Hydraulic fittings and Pipes - XTRA WIDE FLANGE TAPERED PLUG CAP, LDPE YELLOW
60.8
2.395
66.1
2.602
59.0
2.322
64.3
2.530
28.7
1.130
104.1
4.100
200 40 4
XW2.63/2.79YW1 Polyethylene Plug Caps with Extra Wide Flange - XTRA WIDE FLANGE TAPERED PLUG CAP, LDPE YELLOW
67.0
2.638
71.0
2.795
64.7
2.547
67.8
2.670
28.7
1.130
108.2
4.260
200 40 4
Part # Description Small O.D.
mm
in
Large O.D.
mm
in
Small I.D.
mm
in
Large I.D.
mm
in
Length
mm
in
Flange OD
mm
in
Box/Mini/Micro
QTY
See Prices / Buy Online
Legend:
- Add to Basket - View Price

Plug To use as a PLUG:
Select a PLUG with a “B” dimension at least 0.5mm (.020” ) larger than the diameter to be plugged (increase 1% or more for large diameters)
Cap To use as a CAP:
Select a CAP with a “C” dimension at least 0.5mm (.020” ) smaller than the diameter to be capped (increase 1% or more for large diameters)

Micropacks are only available for purchase through our online store.



Not sure what part you need? Would you like to consider another type or part, or a different material?
Consult MOCAP's Application Advisor for assistance.



Thick Extra Wide Flange Tapered Plug Caps - Information

MOCAP Extra Wide Flange Tapered Plastic Plug Caps are inexpensive dual function closures which can be used as either a plug or a cap. These tapered polyethylene plug caps are made from tough but flexible polyethylene to form a secure fit, yet are easily removed.
These Plastic Plugs feature flanges which are thicker and wider than any of our other plug-cap series. Over-sized flanges and the high-visibility colour require removal before assembly operations.
Recommended to use as a cap for tube and hydraulic fittings, tube end caps, pipe caps or product protection. Or use as a plug for threaded holes, openings, fittings and ports.

  • Durable and Flexible - Use as a Cap or Plug
  • Protects Against Debris, Damage, Moisture and Corrosion
  • Many Sizes of Our Thick Extra Wide Flange Tapered Plug Caps are Stocked for Immediate Shipment.



Functions as a Cap
MOCAP's XW Plastic Plug Caps have a tapered design which allow it to be used as a cap for multiple threaded and non-threaded applications.

Functions as a Plug
Use MOCAP XW Tapered Plug Caps to plug a wide range of openings, including threaded and non-threaded holes, pipe and tube end plugs, connector ports and fittings.

Masking Applications
MOCAP Plug Caps can also be used as inexpensive, single use disposable masking caps or masking plugs for painting, coating and spraying processes up to 79°C (175°F).


Many Sizes of Our Thick Extra Wide Flange Tapered Plug Caps are Stocked for Immediate Shipment.


Most stock sizes are available in Mini-Packs when Smaller Quantities are Needed. To place an order for this product, call 0800 856 2466 or use our Contact Request Form to receive information by e-mail.







RoHS


© MOCAP
Diagram
