Hex Socket Plugs for NPT Threads

 0800 046 7436


Hex Socket Plugs for NPT Threads

HSPN


Plastic NPT Bolt with Hex Socket
Hex Socket Plugs for NPT Threads

HSPN–Product Media

Hex Socket Plugs for NPT Threads Plastic Hex Socket Plugs for NPT Threads Hex Socket Threaded Plastic Plug Caps Polypropylene Plastic Hex Socket Plugs for NPT Threads Hex Socket Plugs for NPT Threads Plastic NPT Bolt with Hex Socket Plastic Hex Socket Plugs for NPT Threads Hex Socket Threaded Plastic Plug Caps Polypropylene Plastic Hex Socket Plugs for NPT Threads
  • Material: PP (Polypropylene)
  • Stocked Material: PP (Red)
  • Designed to Protect Threads from Dust, Dirt, and Moisture During Low-Pressure Testing and In-Plant Handling

Size Chart Hex Socket Threaded Plastic Plug Caps

HSPN Size Chart

Table View
List View
Part # Description To Fit NPT Inside Diameter
mm
in
 Inside Length
mm
in
 Length
mm
in
 Box/Mini/Micro
QTY		 See Prices / Buy Online
HSPN0250 Hex Socket Plugs for NPT Threads - HEX SOCKET PLUG FOR 1/4-18 NPT THRDS 1/4 - 18
6.6
0.260
7.9
0.310
12.7
0.500
 3500 700 70
HSPN0375 Polypropylene Plastic Hex Socket Plugs for NPT Threads - HEX SOCKET PLUG FOR 3/8-18 NPT THRDS 3/8 - 18
8.4
0.330
9.7
0.380
14.4
0.566
 4000 800 80
HSPN0500 Hex Socket Threaded Plastic Plug Caps - HEX SOCKET PLUG FOR 1/2-14 NPT THRDS 1/2 - 14
9.9
0.390
9.7
0.380
14.4
0.566
 5000 1000 100
HSPN0750 Plastic Hex Socket Plugs for NPT Threads - HEX SOCKET PLUG FOR 3/4-14 NPT THRDS 3/4 - 14
14.5
0.570
11.9
0.470
15.5
0.610
 2000 400 40
HSPN1000 Plastic NPT Bolt with Hex Socket - HEX SOCKET PLUG FOR 1-11-1/2 NPT THRDS 1 - 11-1/2
16.3
0.640
15.0
0.590
18.8
0.740
 1600 320 32
Part # Description To Fit NPT Inside Diameter
mm
in
 Inside Length
mm
in
 Length
mm
in
 Box/Mini/Micro
QTY		 See Prices / Buy Online
Legend:
- Add to Basket - View Price

Micropacks are only available for purchase through our online store.



Not sure what part you need? Would you like to consider another type or part, or a different material?
Consult MOCAP's Application Advisor for assistance.



Hex Socket Plugs for NPT Threads - Information

MOCAP Hex Socket Plugs are designed for use on NPT threads and fittings. The Socket design allows for threads to be protected during low-pressure testing and in-house processing or handling, however these are not intended for permanent applications.
Protects threaded components from moisture, dust and damage during production, shipping and storage, and can also be used as masking during painting and plating. Our HSPN Series Threaded Plugs are moulded in Red polypropylene plastic and sized to fit NPT threads from 1/4-18 thru 1-11-1/2.

Many Sizes of Our Hex Socket Plugs for NPT Threads are Stocked for Immediate Shipment.


Most stock sizes are available in Mini-Packs when Smaller Quantities are Needed. To place an order for this product, call 0800 046 7436 or use our Contact Request Form to receive information by e-mail.







RoHS


Diagram
