Push-in Flange Protectors

MPI


Plastic Push-in Flange Protective Cover
Push-in Flange Protectors

MPI–Product Media

Push-in Plastic Flange Protectors Plastic Protective Push-in Flange Plugs Plastic Push-in Flange Caps Plastic Push-in Flange Protectors Push-in Flange Protectors Plastic Push-in Flange Protective Cover Plastic Protective Push-in Flange Plugs
  • Material: LDPE (Low Density Polyethylene)
  • Stocked Material: LDPE (Yellow)
  • Designed to Protect Flange Faces from Damage and Debris
  • Flexible Rings Allow for Easy Installation

Size Chart Plastic Push-in Flange Caps

MPI Size Chart

Table View
List View
Part # Description To Fit Nominal Pipe Size DIN Diameter
mm
in
Flange OD
mm
in
Length
mm
in
Box/Mini/Micro
QTY
See Prices / Buy Online
MPI500 Push-in Flange Protectors - Push-in Plastic Flange Protector (Nominal Pipe Size: 1/2") 1/2” DN 15
19.0
0.748
90.0
3.543
15.0
0.591
1000 200 20
MPI750 Plastic Push-in Flange Protectors - Push-in Plastic Flange Protector (Nominal Pipe Size: 3/4") 3/4” DN 20
24.0
0.945
100.0
3.937
15.0
0.591
700 140 14
MPI1000 Plastic Push-in Flange Caps - Push-in Plastic Flange Protector (Nominal Pipe Size: 1") 1 ” DN 25
30.0
1.181
110.0
4.331
20.0
0.787
500 100 10
MPI1250 Plastic Protective Push-in Flange Plugs - Push-in Plastic Flange Protector (Nominal Pipe Size: 1-1/4") 1-1/4” DN 32
39.0
1.535
136.0
5.354
20.0
0.787
300 60 6
MPI1500 Plastic Push-in Flange Protective Cover - Push-in Plastic Flange Protector (Nominal Pipe Size: 1-1/2") 1-1/2” DN 40
45.0
1.772
146.0
5.748
20.0
0.787
250 50 5
MPI2000 Push-in Flange Protectors - Push-in Plastic Flange Protector (Nominal Pipe Size: 2") 2 ” DN 50
56.0
2.205
160.0
6.299
20.0
0.787
200 40 4
MPI2500 Plastic Push-in Flange Protectors - Push-in Plastic Flange Protector (Nominal Pipe Size: 2-1/2") 2-1/2” DN 65
72.0
2.835
180.0
7.087
20.0
0.787
200 40 4
MPI3000 Plastic Push-in Flange Caps - Push-in Plastic Flange Protector (Nominal Pipe Size: 3") 3 ” DN 80
85.0
3.346
196.0
7.717
25.0
0.984
150 30 3
MPI4000 Plastic Protective Push-in Flange Plugs - Push-in Plastic Flange Protector (Nominal Pipe Size: 4") 4 ” DN 100
109.0
4.291
216.0
8.504
25.0
0.984
100 20 2
MPI5000 Push-in Flange Protectors - Push-in Plastic Flange Protector (Nominal Pipe Size: 5") 5 ” DN 125
134.0
5.276
246.0
9.685
25.0
0.984
75 15 1
MPI6000 Plastic Push-in Flange Protectors - Push-in Plastic Flange Protector (Nominal Pipe Size: 6") 6 ” DN 150
161.0
6.339
280.0
11.023
35.0
1.378
40 8 1
MPI8000 Plastic Push-in Flange Caps - Push-in Plastic Flange Protector (Nominal Pipe Size: 8") 8 ” DN 200
210.0
8.268
336.0
13.228
35.0
1.378
40 8 1
MPI10000 Plastic Protective Push-in Flange Plugs - Push-in Plastic Flange Protector (Nominal Pipe Size: 10") 10 ” DN 250
262.0
10.315
390.0
15.354
40.0
1.575
28 5 1
MPI12000 Plastic Push-in Flange Protective Cover - Push-in Plastic Flange Protector (Nominal Pipe Size: 12") 12 ” DN 300
318.0
12.520
450.0
17.717
48.0
1.890
20 4 1
Part # Description To Fit Nominal Pipe Size DIN Diameter
mm
in
Flange OD
mm
in
Length
mm
in
Box/Mini/Micro
QTY
See Prices / Buy Online
Legend:
- Add to Basket - View Price

Micropacks are only available for purchase through our online store.



Not sure what part you need? Would you like to consider another type or part, or a different material?
Consult MOCAP's Application Advisor for assistance.



Push-in Flange Protectors - Information

MOCAP Push-In Flange Protectors are designed to fit many different styles and sizes of Flanges, allowing for maximum flexibility. Designed to protect from damage and contamination during transit, handling and storage, our MPI series products are easy to install and remove.

Suitable for both imperial (ANSI) and metric (DIN) flanges to specifications DIN2627 - 2638, 150, BS 5504 and ANSIB16,5.
Our MPI Series Plugs are moulded in Yellow polyethylene plastic to fit 3/8" thru 12" nominal sized pipe flanges.

Many Sizes of Our Push-in Flange Protectors are Stocked for Immediate Shipment.


Most stock sizes are available in Mini-Packs when Smaller Quantities are Needed. To place an order for this product, call 0800 046 7436 or use our Contact Request Form to receive information by e-mail.
