Paper Tapered Caps

MPTC


Inexpensive Paper End Caps
Paper Tapered Caps

MPTC – Product Media

Paper Tapered Caps High-Temperature Paper Tapered End Cap Tapered Paper Cap Tapered Paper End Caps Paper Tapered Caps Inexpensive Paper End Caps High-Temperature Paper Tapered End Cap Tapered Paper Cap Tapered Paper End Caps
  • Withstands Up to 204°C (400°F) - Ideal for Low-To-High Temp Apps
  • Material: Paper (Brown)
  • Environmentally Friendly and Economical Masking Solution
  • Does Not Promote Condensation
Select your item

Size Chart Tapered Paper Cap

PrintPrint

MPTC Size Chart

Part # Description To Fit MALE NPT To Fit STD Thread To Fit METRIC Thread To Fit BSP Small I.D.
mm
in
Large I.D.
mm
in
Inside Length
mm
in
Box/Mini/Micro
QTY
See Prices / Buy Online
MPTC002 Paper Tapered Caps - TAPERED CAP, PAPER - TAN 1/8 3/8 M10 G1/8
9.0
0.354
10.1
0.398
10.1
0.398
25000 1000 100
MPTC003 Tapered Paper End Caps - TAPERED CAP, PAPER - TAN 1/4 1/2, 9/16, 5/8 M14,M15
11.9
0.469
12.4
0.488
13.5
0.532
12000 1000 100
MPTC004 Tapered Paper Cap - TAPERED CAP, PAPER - TAN 1/2, 9/16, 5/8 M14,M15 G1/4, G3/8
12.3
0.484
19.0
0.748
22.4
0.882
5800 1000 100
MPTC006 High-Temperature Paper Tapered End Cap - TAPERED CAP, PAPER - TAN 3/8 3/4 M18 G3/8
16.5
0.650
16.5
0.650
13.1
0.516
16000 1000 100
MPTC007 Inexpensive Paper End Caps - TAPERED CAP, PAPER - TAN 1/2 13/16, 7/8 M20 G1/2
19.7
0.776
21.2
0.835
19.5
0.768
7000 1000 100
MPTC008 Paper Tapered Caps - TAPERED CAP, PAPER - TAN 15/16, 1 M22,M24 G5/8
20.6
0.811
24.2
0.953
21.2
0.835
5500 1000 100
MPTC009 Tapered Paper End Caps - TAPERED CAP, PAPER - TAN 1 M25,M26 G5/8, G3/4
22.0
0.866
26.6
1.047
16.7
0.657
6200 1000 100
MPTC010 Tapered Paper Cap - TAPERED CAP, PAPER - TAN 3/4 1, 1-1/16 M25,M26, M27 G3/4
24.1
0.949
27.3
1.075
22.5
0.886
4000 800 80
MPTC011 High-Temperature Paper Tapered End Cap - TAPERED CAP, PAPER - TAN 1-3/16, 1-1/4 M30, M32 G7/8
28.6
1.126
33.0
1.299
18.2
0.717
3500 700 70
MPTC012 Paper Tapered Caps - TAPERED CAP, PAPER - TAN 1 M32 G1
32.2
1.268
32.0
1.260
25.3
0.996
3300 660 66
MPTC013 Tapered Paper End Caps - TAPERED CAP, PAPER - TAN 1-7/16, 1-1/2 M35,M36, M38
33.3
1.311
38.6
1.520
17.8
0.701
3200 640 64
MPTC014 Tapered Paper Cap - TAPERED CAP, PAPER - TAN 1-1/2 M38, M39, M40
36.7
1.445
41.2
1.622
20.6
0.811
3000 600 60
MPTC015 High-Temperature Paper Tapered End Cap - TAPERED CAP, PAPER - TAN 1-1/4 M42 G1-1/4
41.0
1.614
42.8
1.685
21.5
0.846
2700 540 54
MPTC016 Inexpensive Paper End Caps - TAPERED CAP, PAPER - TAN 1-3/4, 1-13/16, 1-15/16, 2 M45,M48,M50
42.5
1.673
51.1
2.012
18.3
0.720
2500 500 50
MPTC017 Paper Tapered Caps - TAPERED CAP, PAPER - TAN 1-1/2 1-7/8 M48 G1-1/2
46.4
1.827
48.0
1.890
23.9
0.941
1800 360 36
MPTC018 Tapered Paper End Caps - TAPERED CAP, PAPER - TAN 2 M60 G2
59.1
2.327
59.5
2.343
22.0
0.866
1400 280 28
MPTC019 Tapered Paper Cap - TAPERED CAP, PAPER - TAN 2-5/8, 2-3/4 M68,M70, M72
65.7
2.587
72.3
2.846
24.9
0.980
1000 200 20
MPTC020 High-Temperature Paper Tapered End Cap - TAPERED CAP, PAPER - TAN 2-1/2 M72
71.8
2.827
72.3
2.846
24.6
0.969
800 160 16
MPTC021 Paper Tapered Caps - TAPERED CAP, PAPER - TAN 3 3-3/8, 3-1/2 M85,M90
84.2
3.315
92.2
3.630
28.3
1.114
500 100 10
Part # Description To Fit MALE NPT To Fit STD Thread To Fit METRIC Thread To Fit BSP Small I.D.
mm
in
Large I.D.
mm
in
Inside Length
mm
in
Box/Mini/Micro
QTY
See Prices / Buy Online
Legend:
- Add to Basket - View Price

Micropacks are only available for purchase through our online store.



Not sure what part you need? Would you like to consider another type or part, or a different material?
Consult MOCAP's Application Advisor for assistance.

NOTE:
  • Part dimensions are typical from a measured lot. Individual pieces may vary.
  • Due to the material, this product may have minor dimensional variation due to changes in relative humidity.
  • Flange concentricity may vary.
  • Due to paper's natural structure, the product may be oblong in free state. This will generally aid in the product's retention capability.




Paper Tapered Caps - Information

MOCAP Paper Tapered Caps are an environmentally friendly and economical masking solution. Made of recyclable paper, these tapered paper caps do not promote condensation. These closures will withstand up to 204°C (400°F), making them ideal for low-to-high temperature applications.
Note: Due to the material, these Tapered Paper Caps may have minor dimensional variation due to changes in relative humidity.
Our MPTC Series Caps are manufactured in tan paper and sized to fit 1/8 thru 3 inch male NPT pipes

Many Sizes of Our Paper Tapered Caps are Stocked for Immediate Shipment.


Most stock sizes are available in Mini-Packs when Smaller Quantities are Needed. To place an order for this product, call 0800 856 2466 or use our Contact Request Form to receive information by e-mail.
